Communication Cable FTTH Flat Fiber Optic/Optical Drop Cable 1

Communication Cable FTTH Flat Fiber Optic/Optical Drop Cable 1

Overview Package Size45.00cm * 45.00cm * 35.00cm Package Gross Weight42.000kg Supply FTTH flat fiber optic cable with LS
SHARE
Send inquiry

Description

  • Overview
  • Product Description
Overview
Basic Info.
Model NO. GJYXCH
Material Shape Flat Wire
Allowed Lateral Pressure 100(N/100mm)<1000(N/100mm)
Allowed Tensile Strength 1000N<10000N
Core Multicore
Certification RoHS, ISO9001, CCC, SGS,UL,RoHS,ISO 9001-2008,Tlc,Ce.
Brand OEM
Sheath Material PVC ,LSZH ,PU
Outsheath PVC,LSZH.
Laying Method FTTH/FTTX/Ftta
Fiber Count 1-12 Cores
Number of Conductors 2
Fiber Type G652D,G657A,Om1,Om2,Om3,Om4
Package 1km/Roll,2km/Roll or Customized
Color Black,White or Customized
Transport Package Plywood Drum with Cartons
Specification 450mm*450*350mm
Trademark NECERO
Origin Guangdong, China
Packaging & Delivery
Package Size45.00cm * 45.00cm * 35.00cm Package Gross Weight42.000kg
Product Description

Supply FTTH flat fiber optic cable with LSZH Jacket Mini type (1-12 core) for telecommunication

We are 20 years fiber optic cable manufacturer. Welcome to go to the factory tour! Send message to us can get free samples.

Product Description
G.652 G.657 50/125μm 62.5/125μm
Attenuation
(+20ºC)		 @850nm ≤3.5 dB/km ≤3.5 dB/km
@1300nm ≤1.5 dB/km ≤1.5 dB/km
@1310nm ≤0.40 dB/km ≤0.40 dB/km
@1550nm ≤0.30 dB/km ≤0.30dB/km
Bandwidth (Class A) @850nm ≥500 MHz·km ≥200 MHz·km
@1300nm ≥500 MHz·km ≥500 MHz·km
Numerical Aperture 0.200±0.015NA 0.275±0.015NA
Cable Cut-off Wavelength ≤1260nm ≤1260nm

Product Description

Communication Cable FTTH Flat Fiber Optic/Optical Drop Cable 1-12cores LSZH Mini Type with Anatel

Communication Cable FTTH Flat Fiber Optic/Optical Drop Cable 1-12cores LSZH Mini Type with Anatel

Communication Cable FTTH Flat Fiber Optic/Optical Drop Cable 1-12cores LSZH Mini Type with Anatel

Communication Cable FTTH Flat Fiber Optic/Optical Drop Cable 1-12cores LSZH Mini Type with Anatel

Communication Cable FTTH Flat Fiber Optic/Optical Drop Cable 1-12cores LSZH Mini Type with Anatel


Related Products

Company Information

FAQ

1.Are you the real factory

Yes,we are the real factory with 20 years' history.

2.What is your fiber brand ?

We use fibers from YOFC, FIBERHOME,USA Corning or any other fiber brand according clients request.

3.What is your main products

Outdoor fiber optic cables; indoor fiber optic cables;FTTH Drop cables; ADSS;

Indoor armored patch cords fiber cable; Optical patch cords SC/LC/FC/ST; MTP/MPO optical patch cord.

4.Product quality guarantee period?

25 years' Guarantee for fiber optic cable

5.Do you have certificate for raw material ?

We build long-term relationship cooperation with qualified ISO9001, ROHS raw material suppliers.

6.What is your delivery time?

Within 24 hours for 30KM normal kinds of fiber optic cable;

1 ~2 days for fiber optic patch cords with 10000 connectors.
