Low Frictional Coefficient Rubber
Description
Basic Info.
| Model NO. | indoor cable |
| Core | Multicore |
| Certification | CE, ISO9001 |
| Brand | OEM |
| Sheath Material | Lszh |
| Number of Conductors | 2 |
| Outer Jacket | Lszh,Mdpeetc |
| Operation Temp | -20~ +70 |
| Central Strength Member | Kevlar |
| Cable Color | Yellow |
| Strengthen Member | Kelver |
| Certificate | ISO9001 and CE |
| Model Number | Armored Cable |
| Place of Origin | Zhejiang, China (Mainland) |
| Cores | 652D or 657A |
| Transport Package | Packed on Fumigated Iron-Wooden |
| Specification | CE ISO9001 |
| Trademark | jinlong |
| Origin | China Zhejiang |
| HS Code | 8544700000 |
| Production Capacity | 500 Kilometer/Kilometers Per Week |
Product Description
Packaging & DeliveryPackaging Details: Wooden Drum for long term shipping
Delivery Detail: 15~20 Days
Specifications
G657 Fiber FTTH Drop Cable 1.For LAN & building. 2.Self-supporting cable 3.Fiber to the desk optical cable 4.RoHS certificate
FTTH Drop Fiber Cable
1. A single mode splitter has one input port and multiple output ports for dividing an optical signal.
2. SAILING fiber optic splitter is the planer waveguide integrated optic device which based on the quartz substrate, with small size, wide field operation wavelength and high reliability.
Technical characteristics
-G657 fiber put in the cable, ensure the very good micro-bending resistant performance.
-Simple structure ,light weight and high practicability.
-Novel flute design easily strip and splice, simplify the installation and maintenance.
-Two parallel FRP or Aramid plastic rods strengthen ensure good performance of crush and tension resistance to protect the fiber.
-Low smoke, zero halogen and flame retardant sheath.
Description :
The φ250μm colored coating optical fibers are positioned in the centre. The parallel fiber reinforced plastics (FRP) are placed at the two sides. A steel wire as the additional strength member is also applied. Then the cable is completed with a black or color LSZH sheath.
Technical Advantages:
1. Special low-bend-sensitivity fiber provides high bandwidth and excellent transmission property.
2. Single steel wire ensures crush resistance to protect fiber.
3. Simple structure, light weight and high practicability
4. Novel flute design, easily strip and splice, simplify installation and maintenance.
5. Flexible network construction, reduce the cost of installation and convenient for network management.
6. Usable equipment ports, easy to increase the user and expand accommodates gradually.
Application:
Used in pigtails and cords;in optical connetions in optical communication equipment rooms and optical distribution frames;in optical connections in optical apparatus equipment.
| Technical Data | |||||||||
| Fiber count | Cable outer dia (mm) | Tight-buffered fiber dia (mm) | Cable weight (kg/km) | Min.bending radius(mm) | Permissible tensile force(N) | Permissible pressure force(N/100mm) | |||
| Static | Dynamic | Short-term | Long-term | Short-term | Long-term | ||||
| 2 | 1.6*3.3 | 0.6 | 5.8 | 60 | 30 | 120 | 60 | 500 | 100 |
| 2 | 1.8*3.7 | 0.6 | 7.4 | 60 | 30 | 120 | 60 | 500 | 100 |
| 2 | 2.0*4.1 | 0.9 | 10.0 | 60 | 30 | 150 | 80 | 500 | 100 |
| 2 | 2.4*4.9 | 0.9 | 11.4 | 60 | 30 | 150 | 80 | 500 | 100 |
| 2 | 2.8*5.7 | 0.9 | 15.8 | 60 | 30 | 200 | 100 | 500 | 100 |
| 2 | 3.0*6.1 | 0.9 | 16.2 | 60 | 30 | 200 | 100 | 500 | 100 |
| G.657,15mm. | |||||||||
| The minimum bend radius(static)is 15mm when G.657 fiber is used. | |||||||||
| Temperature Range | |||||||||
| Transport/Storage temp | -20ºC~ +70ºC | ||||||||
| Installation temp | -5ºC~ +50ºC | ||||||||
| Operation temp | -20ºC~ +70ºC | ||||||||
| Item | FTTH-6 |
| Number of Fiber | 6( G652D) |
| Two paraller strength member | FRP rod |
| Outer sheath (LZSH suit for very low temperature) | LSZH PE |
| Outer sheath colour | white or similar |
| Permissible bending radius | 25mm |
| Self-support distance | -- |
| Permissible tensile force | 100-120N |
| Cable diameter | |
| Width | 4.0 + 0.1 mm |
| Height | 2.0 + 0.1mm |
| Weight (apporx) | 9.0kg/km + 1Kg/Km |
| Operating temperature range | -40oC to +60oC |
| Storage / Transport temperature range | -40oC to +60oC |
| Installation temperature range | -40oC to +60oC |
| Product Model | GJXCH/GJXFCH | |||||
| Product Name | Self- supporting metallic strength member optical fiber drop cable | |||||
| size | 5.2×2.2MM | |||||
| Attenuation index | wavelength | B1.1 B1.3 | B6a(G.657A) | B6b(G.657b) | ||
| (G.652) | (DB/KM) | (DB/KM) | ||||
| (DB/KM) | ||||||
| 1310 | ≤0.45 | ≤0.45 | ≤0.60 | |||
| 1550 | ≤0.30 | ≤0.30 | ≤0.50 | |||
| Technical parameter | Model | Fiber count | Fiber model | Max.tensile (N) | Max.squashed force (N) | Max.Bending radius |
| Long-time/ | Long-term/ | Long-time/ | ||||
| short-time | short time | Short-time | ||||
| CJYXCH/GJYXFCH | 4 | B1.1 B1.3 | 300/600 | 1000/2200 | 30/60 | |
| B6a | 300/600 | 1000/2200 | 15/30 | |||
| B6b | 300/600 | 1000/2200 | 10/25 | |||
| GJYXCH/ GJYXFCH | 1/2 | B1.1 B1.3 | 300/600 | 1000/2200 | 30/60 | |
| B6a | 300/600 | 1000/2200 | 15/30 | |||
| B6b | 300/600 | 1000/2200 | 10/25 | |||
| Length type | 500M 1000M 2000M per reel or as your request | |||||
